优化挤压辊参数设计消除高频焊管表面缺欠

介升旗, 陈浩明, 杨喜峰

介升旗, 陈浩明, 杨喜峰. 优化挤压辊参数设计消除高频焊管表面缺欠[J]. 钢管, 2021, 50(5): 47-49. DOI: 10.19938/j.steelpipe.1001-2311.2021.5.47.49
引用本文: 介升旗, 陈浩明, 杨喜峰. 优化挤压辊参数设计消除高频焊管表面缺欠[J]. 钢管, 2021, 50(5): 47-49. DOI: 10.19938/j.steelpipe.1001-2311.2021.5.47.49
JIE Shengqi, CHEN Haoming, YANG Xifeng. Eliminating Surface Imperfection of High Frequency Welded Pipe by Optimizing Parameter Design of Squeeze Roller[J]. STEEL PIPE, 2021, 50(5): 47-49. DOI: 10.19938/j.steelpipe.1001-2311.2021.5.47.49
Citation: JIE Shengqi, CHEN Haoming, YANG Xifeng. Eliminating Surface Imperfection of High Frequency Welded Pipe by Optimizing Parameter Design of Squeeze Roller[J]. STEEL PIPE, 2021, 50(5): 47-49. DOI: 10.19938/j.steelpipe.1001-2311.2021.5.47.49

优化挤压辊参数设计消除高频焊管表面缺欠

详细信息
    作者简介:

    介升旗(1971-),男,高级工程师,主要从事高频焊管成型及焊接工艺的研究。

Eliminating Surface Imperfection of High Frequency Welded Pipe by Optimizing Parameter Design of Squeeze Roller

  • 摘要: 分析高频焊管机组上挤压辊造成焊接管坯表面压痕、熔融金属压坑等缺欠的原因,并对上挤压辊进行调整和优化:通过增大上挤压辊孔型半径,增加了上挤压辊的“后跟隙”,有效地消除了焊接管坯表面的直线形压痕;通过减小挤压辊辊面宽度,增加了上挤压辊的辊缝,有效地消除了焊接管坯焊缝附近的焊瘤压坑。
    Abstract: Analyzed are the imperfection on the welded pipe surface such as indentation and molten metal pit,etc.as caused by the upper squeeze roll of the high-frequency welding pipe mill,and accordingly the upper squeeze roll of the pipe mill is properly adjusted and optimized.Relevant actions are taken,including enlarging the radium of the upper extrusion roll to get the“heel gap”thereof increased so as to obviously eliminate the line indentation on the pipe surface,and reducing the surface width of the said roll to enlarge the gap thereof so as to properly eliminate the overlap indented pit near the weld seam of the blank pipe.
计量
  • 文章访问数:  11
  • HTML全文浏览量:  0
  • PDF下载量:  3
  • 被引次数: 0
出版历程
  • 收稿日期:  2020-12-20
  • 修回日期:  2021-01-10
  • 网络出版日期:  2023-12-12
  • 刊出日期:  2021-10-30
