一种360°全景管道内窥镜的设计与应用

详细信息

Design and Application of a 360° Panoramic Endoscope for Pipe and Pipeline

摘要: 介绍了一种应用于大直径钢管或压力管道内表面检测用的内窥镜装置及设计方案，分析了该装置的结构、原理和技术特点。分析认为：该装置通过网络通信实现动作控制及图像数据传输，通过组合多个摄像头实现内壁360°全覆盖检测，能够直观发现钢管及压力管道内壁存在的各种表面缺陷，并可快速地对缺陷进行定位、定量分析。
- 钢管 /
- 工业内窥镜 /
- 全景摄像头
Abstract: Described here in the paper are an endoscope device used for detecting the inner surface of the large-sized steel pipe and the design scheme thereof.Also analyzed are the structure,principle and technical characteristics of the said device.The facts as follows are revealed via the analysis.The device is capable of movement control and image and data transmission with network communication,and 360° full coverage detection of the inner surface via integrated multiple cameras so as to directly identify various surface defects on the inner surface of the steel pipe or the pressure pipeline,and moreover get the defect rapidly located and quantitatively analyzed.
- steel pipe /
- industrial endoscope /
- panoramic camera
